* Compilation: javac PolygonTransform.java
* Execution: java PolygonTransform
*
* @author: Karen Li
*
*************************************************************************/
public class PolygonTransform{
// Returns a new array that is an exact copy of the given array.
// The given array is not mutated.
public static double[] copy(double[] array) {
double[] x = new double[array.length];
for (int i = 0; i < array.length; i++){
x[i] = array[i];
}
return x;
}
// Scales the given polygon by the factor alpha.
public static void scale(double[] x, double[] y, double alpha) {
for (int i = 0; i < x.length; i++){
x[i] = alpha * x[i];
y[i] = alpha * y[i];
}
}
// Translates the given polygon by (dx, dy).
public static void translate(double[] x, double[] y, double dx, double dy) {
for (int i = 0; i < x.length; i++){
x[i] = x[i] + dx;
y[i] = y[i] + dy;
}
}
// Rotates the given polygon theta degrees counterclockwise, about the origin.
public static void rotate(double[] x, double[] y, double theta) {
double rad = Math.toRadians(theta);
double a;
for (int i = 1; i < x.length; i++){
a = x[i];
x[i] = x[i] * Math.cos(rad) - y[i] * Math.sin(rad);
y[i] = y[i] * Math.cos(rad) - y[i] * Math.sin(rad);
}
}
// Tests each of the API methods by directly calling them.
public static void main(String[] args) {
double [] x = {0.0, 1.0, 1.0, 0.0};
double [] y = {0.0, 0.0, 2.0, 1.0};
StdDraw.setScale(-5.0, +5.0);
double alpha = 2.0;
StdDraw.setPenColor(StdDraw.RED);
StdDraw.polygon(x, y);
scale(x, y, alpha);
StdDraw.setPenColor(StdDraw.BLUE);
StdDraw.polygon(x, y);
//Translates polygon by (2, 1).
StdDraw.setScale(-5.0, +5.0);
double dx = 2.0, dy = 1.0;
StdDraw.setPenColor(StdDraw.RED);
StdDraw.polygon(x, y);
translate(x, y, dx, dy);
StdDraw.setPenColor(StdDraw.BLUE);
StdDraw.polygon(x, y);
// Rotates polygon 45 degrees.
StdDraw.setScale(-5.0, +5.0);
double theta = 45.0;
StdDraw.setPenColor(StdDraw.RED);
StdDraw.polygon(x, y);
rotate(x, y, theta);
StdDraw.setPenColor(StdDraw.BLUE);
StdDraw.polygon(x, y);
}
}
